Learn How to Remove Distribution Point Role DP | SCCM | ConfigMgr

I have published the install configuration manager distribution point guide in the previous post.

In this post, you shall learn how to remove/reinstall the distribution point (Remove Configuration Manager Distribution Point). ConfigMgr|SCCM Remove Distribution Point Role Guide.

IMPORTANT! – When you remove a configuration manager distribution point, all the packages distributed to that DP shall get removed. You might need to deploy containers to the DP again even if you reinstate it.

Remove Distribution Point Role

Let’s see how to remove/uninstall a configuration manager distribution point. The following are the steps you need to follow:

Patch My PC
  • Navigate – \Administration\Overview\Site Configuration\Servers and Site System Roles
  • Right Click on Distribution Point and Select Remove
  • Click on Yes to confirm the removal of the DP role from the site system server

Prerequisite – Make sure the SCCM remote site server computer account is part of the Local Administrators group before removing the distribution point role on a site system server.

Remove Distribution Point Role
SCCM Distribution Point – Removal – ConfigMgr|SCCM Remove Distribution Point Role

Log Files to Confirm SCCM DP Distribution Point Removal – HMAN.log

You can review the Hman.log log file to know the status of the successful completion of the Configuration manager distribution point removal process.

Let’s check Log Files to Confirm SCCM DP Distribution Point Removal – HMAN.log.

Remove Distribution Point Role
HMAN.log to check the removal of SCCM DPRemove Distribution Point Role.
Server Info of site TP4 has not changed.HMAN will not update the DPInfo table in the database.
Distribution Points of site TP4 have changed. Update the DistributionPoints table in the database.
Updated DP ["Display=\\SCCMTP2.Intune.com\"]MSWNET:["SMS_SITE=TP4"]\\SCCMTP2.Intune.com\. DBCRC:3C53E82D,NewCRC:7635C56,Action:0,PDP:0,PullDP:0
Server Info of site
TP4 has changed. Update the DPInfo table in the database.
Distribution Points of site TP4 have changed. Update the DistributionPoints table in the database.
Updated DistributionPoints [["Display=\\SCCMTP2.Intune.com\"]MSWNET:["SMS_SITE=TP4"]\\SCCMTP2.Intune.com\], set action to 3. DP will be deleted for this site
No need to remove default DP sender address for distribution point
[["Display=\\SCCMTP2.Intune.com\"]MSWNET:["SMS_SITE=TP4"]\\SCCMTP2.Intune.com\], since it does not exists for this distribution point

Reinstall Distribution Point Role

You need to follow the installation process I explained in the previous blog post to reinstall the Configuration Manager (SCCM) Distribution Point.

Adaptiva
Remove Distribution Point Role
Install Configuration Manager Distribution Point – Remove Distribution Point Role

Resources – Remove a Distribution Point

3 thoughts on “Learn How to Remove Distribution Point Role DP | SCCM | ConfigMgr”

  1. Hello,

    i have a branch office will the bandwith is 6,2 4 Mo.

    I want to know if are sufficient to install a Distribution Point.

    Best regards,
    Jack Holman

    Reply
    • It depends on the content/packages/applications source files that you distribute to remote DP. I normally try to avoid creating remote DPs when it’s at the end of saturated WAN network.

      Reply
  2. I have some sites with 10 Mbits and 40 Users or more, and the majority of sites they have 2 Mbits link to datacenter where my SCCM server is installed so, for you it is recommanded to link these sites with 2 Mbits to datacneter ?

    Reply
