SCCM CMPivot Standalone Version Installation Guide ConfigMgr

Let’s understand the process of deploying & installing the CMPivot standalone version on Windows 10. Configuration Manager CMPivot tool allows us to quickly assess the state of online devices. In this example, the CMPivot standalone version is installed on a Windows 10 device where SCCM console is installed

When we run a query against a device collection, the CMPivot shall run a query in real-time on all currently connected (online) devices in the selected collection. The following post includes CMPivot architecture and communication details as well. 👉SCCM CMPivot Architecture Fast Channel Making | ConfigMgr.

Source Files for CMPivot

Let’s copy the source files of CMPivot from site server to package source location.

  • Copy Source File – \Cmmemcm\f$\Program Files\Microsoft Configuration Manager\tools
  • Destination Folder – \CMMEMCM\Sources\Package Sources\CMPivot
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr

Create CMPivot Application

  • Launch ConfigMgr console.
  • Navigate via Software LibraryApplication ManagementApplications
  • Right-click on applications not and select Create Application option
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr

Import CMPivot MSI to SCCM

  • Click on the Browse button to select the application source files.
    • This helps to Automatically detect information about this application from the install file of CMPivot (CMPivot.msi).
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr 1
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
  • Browse to the package source folder as mentioned above.
  • Select the cmpivot.msi and click on OPEN button.
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
  • Let’s check the location is populated with the package source path as shown below.
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
  • Click NEXT & NEXT to continue to the next screen
  • Following is the imported information.
Application name: CMPivot
Publisher:
Software version:
Deployment type name: CMPivot - Windows Installer (*.msi file)
Product Code: {60F9F9C2-04F4-470C-810E-BEF7C960F970}
Installation behavior: Install for system
Content location: \CMMEMCM\Sources\Package Sources\CMPivot\
Number of files: 1
Content files:
cmpivot.msi

General Information about CMPivot.MSI

  • Enter the Name of the Application – CMPivot
  • Enter the Publisher Name – Microsoft
  • Installation Command – msiexec /i “cmpivot.msi” /q
  • Installation Behaviour – Install for System
  • Click on NEXT to continue
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
  • Let’s confirm the application details from the below details and click NEXT to continue.
General Information:
• Application name: CMPivot
• Administrator comments:
• Publisher: Microsoft
• Software version:
• Optional reference:
Categories:
Deployment type name: CMPivot - Windows Installer (*.msi file)
Requirement rules:
Content:
• Content location: \CMMEMCM\Sources\Package Sources\CMPivot\
• Installation program: msiexec /i "cmpivot.msi" /q
Detection Method:
• Product code: {60F9F9C2-04F4-470C-810E-BEF7C960F970}
User Experience:
• Installation behavior: Install for system
  • Click on NEXT, NEXT, and Close to complete the Application Creation Wizard.
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr

CMPivot Deployment Types

Let’s check the CMPivot deployment type that we created in the above section.

  • Priority – 1
  • Name – CMPivot – Windows Installer (*.msi file)
  • Dependencies – No
  • Technology Title – Windows Installer (*.msi file)
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr

Distribute & Deploy CMPivot

  • Right-click on CMPivot application and
  • Select the option called Deploy
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
  • Click on Browse
  • Select the device collection to deploy CMPivot standalone application.
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr

Add Distribution Points

  • Now, let’s add the distribution point.
  • Click the Add button from an additional distribution point.
  • Select the option Distribution Point.
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
  • Select the Distribution Points that you want to distribute the package.
  • Click OK and Next to continue.
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr

Deployment Settings

  • Select Action as Install
  • Select Purpose as Available
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr 2
  • Specify the schedule for this deployment
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr 3
  • Click on the Next button from the User experience wizard page by selecting the default settings.
  • Click on the Next button from the Alert wizard page by selecting the default settings.
  • Click on the Next button from the Summary Page.
General (Summary of the deployment)
• Software: CMPivot
• Collection: HTMD Collection (Member Count: 1)
• Use default distribution point groups associated to this collection: Disabled
• Automatically distribute content for dependencies: Enabled
Deployment Settings
• Action: Install
• Purpose: Available
• Allow end users to attempt to repair this application: Disabled
• Allow clients to use a metered Internet connection to download content: Disabled
Application Settings (retrieved from application in software library)
• Application Name: CMPivot
• Application Version:
• Application Deployment Types: Windows Installer (*.msi file)
Scheduling
• Time based on: UTC
• Available Time: As soon as possible
• Deadline Time: Disabled
• Delayed enforcement on deployment: Disabled
User Experience
• User notifications: Display in Software Center, and only show notifications for computer restarts
• Ignore Maintenance Windows: Disabled
• System restart (if required to complete the installation): Disabled
• Commit changes at deadline or during a maintenance window (requires restarts): Enabled
Alerts
• Enable System Center Operations Manager maintenance mode: Disabled
• Generate System Center Operations Manager alert when a software installation fails: Disabled
• Create a deployment alert when the threshold is lower than the following: Disabled
• Create a deployment alert when the threshold is higher than the following: Disabled
Content (2):
• CMMEMCM.MEMCM.COM
• MEMCMSECONDARY.MEMCM.COM
  • Click on Next and Close button to complete the wizard.
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr 4

Results

I have deployed the CMPivot standalone version to the Windows 10 device that already have ConfigMgr Console installed.

Related post – Install SCCM Console on a Remote Windows 10 Devices | ConfigMgr

  • Once the deployment is created, you can see the below.
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr 5
  • Let’s check content status.
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr 6
  • Check the Software Center from Windows 10 client
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
  • Shortcut of CMPivot got created on Windows 10 device.
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
  • Successfully Launched CMPivot
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
SCCM CMPivot Standalone Version Installation Guide | ConfigMgr
