[Fix] List of SCCM 1806 Known Issues – Documented

Let us learn about [Fix] List of SCCM 1806 Known Issues – Documented. SCCM 1902 Production Upgrade GuideMicrosoft released a couple of update rollups (hotfixes) for the latest production version of SCCM 1806.

In this post, I will explore the SCCM 1806 known issues and how to fix those known issues. The video tutorial will help you understand how to install SCCM 1806 hotfix.

The Microsoft SCCM team has already fixed SCCM 1806 known issues. Microsoft has released two hotfixes to fix all the documented known issues for the 1806 version of SCCM.

So, all the issues highlighted in the post are already fixed with the latest hotfixes or the latest version of 1806.

Patch My PC
[sibwp_form id=2]

Fix to SCCM 1806 Known Issues?

Microsoft fixed many issues in the latest version, SCCM 1810. Also, Microsoft updated the fixed list of issues in the KB 4482169.

[Fix] List of SCCM 1806 Known Issues - Documented - Fig.1
[Fix] List of SCCM 1806 Known Issues – Documented – Fig.1

SCCM updates and servicing are intelligent enough to filter out unwanted updates and hotfixes from your SCCM console.

So, if your SCCM environment requires an update, it will most likely be visible in your SCCM console.

Updated on 25th Oct

Microsoft Released RollUP update KB 4462978  for SCCM 1806.

Adaptiva
https://support.microsoft.com/en-us/help/4462978/system-center-configuration-manager-version-1806-update-rollup

This update, KB 4462978, replaces the previous update, KB 4346645 or KB 4459354, depending on the different SCCM first-wave versions.

Updated on 2nd Oct

Microsoft released another hotfix for SCCM 1806.

https://support.microsoft.com/en-us/help/4465865/software-updates-do-not-download-in-configmgr-if-wsus-is-disconnected

How to Confirm Hotfix is Required for SCCM Environment?

You can confirm whether the SCCM 1806 hotfix is required for your environment by comparing the SCCM updates and servicing package guide

To verify which wave build is installed, look for a package GUID by adding the Package GUID column to the details pane of the Updates and Servicing node in the SCCM console.

SCCM 1806 Known Issues
[Fix] List of SCCM 1806 Known Issues – Documented 2

List of SCCM 1806 Known Issues

The following list provides SCCM 1806 Known issues. I will try to update it whenever Microsoft releases new hotfixes.

  1. After the WDS-less PXE responder service is configured after an upgrade to SCCM 1806, it may reject PXE-boot requests from clients when the management point (MP) is remote.
  2. Task sequences that have a restart action before an Install Packages action may fail. SCCM 1806 Known Issues fixed.
  3. Unable to delete a secondary site. After the deletion action, the area remains in either an “active” or “deleting” state.
  4. CMPivot cannot run a PowerShell script that contains a command to retrieve a registry entry if the registry contains a NULL value.
  5. The SCCM console crashes if you create or edit an ADR and set the deployment package to “No deployment package.”
  6. CMPivot is missing the “not like” operator.
  7. CMPivot fails to run a PowerShell script that contains a command to retrieve a registry entry if the registry value contains a NULL.
  8. Ccmexec crashes continuously when Pull DPs are installed.
  9. OfflineServicingMgr fails to find the content library location when the Content Library is on a Universal Naming Convention (UNC) path.
  10. If OfflineServicingMgr fails to find the content library location on a UNC path, it leaks the handle and decreases performance.
  11. When you edit an existing co-management policy, instead of saving the changes, the policy is reset to the default state of No AutoEnroll, all workloads are set to SCCM, and pilot collection is empty.
  12. CRP certificate revocation is slowly processing and blocking the main thread in SMS_CERTIFICATE_MANAGER.
  13. On upgrade, if you have deployments requiring approvals referencing built-in CIs created before 1706, you will see significant SQL I/O and high CPU utilization on the MPs as the CIs and deployments are updated.
  14. Phased Deployment Status Wizard shows multiple rows for the same phase with inconsistent data when a collection has machines spread across multiple sites.
  15. The count of AADJoined and HybridAADJoined may be incorrect on the Co-Management dashboard.
  16. Excessive client request time-outs on the cloud management gateway.
  17. After an upgrade to 1806, the site’s performance may decrease due to high I/O and CPU use by sp_UpdResPolicyMap_PolicyAssignment.
  18. Super peers may fail to download partial content when the management point is remote.
  19. The state message component SMS_STATE_SYSTEM was reported as critical because of a backlog of script state messages with no output data reported as corrupt.
  20. Download fails when you use the CCM client Delta Download channel to download express updates full files.
  21. The process MP_GetSuperPeerContentLocations stored proc may cause decreased SQL performance and block threads.
  22. Pull DPs may fail to be upgraded because MOFCOMP silently fails when the Distribution Manager runs it. If the Pull DPs are not upgraded, content cannot be downloaded.
  23. The online client status chart on the CMG Dashboard does not correctly aggregate hourly data from multiple MPs.
  24. When you create an SRM-based CMG or CDP using an existing resource group, the region of the resource group is used to create the resources regardless of the region that you specified.
  25. The DP upgrade fails if PXE is not enabled without WDS.
  26. CMPivot returns NULL if any registry entity values are NULL.
  27. BCP for BGB_NetworkInfo lives data fails if the same subnet exists for the same IP address and client.
  28. CMG HTTP listener stops because of an HttpListenerException.
  29. After WDS-Less PXE is enabled, some clients may not start Task Sequence Wizard because a password is incorrectly expected when multiple clients begin simultaneously. SMSTS.log shows that the password is incorrect even though the wizard is not displayed and no password is set. SCCM 1806 Known Issues fixed.
  30. The state message files in the management point staging folder may not process on a passive site server.
  31. The WDS-less PXE responder service, configured after the upgrade to SCCM 1806, may reject PXE-boot requests from clients when the management point (MP) is remote.
  32. AtomicUpdate and BundledUpdate metadata used for delta download can get truncated. This causes Unified Update Platform (UUP) updates not to be downloaded.
  33. When the SCCM-generated certificate option is selected for the site, and a client fails to download content because it does not have the client public key infrastructure (PKI) certificate, even if the client is restarted, it will still fail to download content even if token-based content locations are available.
  34. After the 1806 upgrade, SCCM clients fail to send client or Management Point (MP) communication status Fallback Status Point (FSP) messages.
  35. When content downloads from delta download or CMBITSMgr, the optimal content location is not chosen for all content within a package.
  36. Some client state messages may not be sent, resulting in some reports such as co-management, Windows Upgrade for Business, and deployment upgrade reporting being out of sync. SCCM 1806 Known Issues fixed.
  37. An Internet-only AAD-joined device cannot register if an MP was removed from the cloud management gateway.
  38. Task sequences that have a restart action before an Install Packages action may fail.
    Unable to delete a secondary site. After the deletion action, the area remains in either an “active” or “deleting” state.
  39. After updating to SCCM, version 1806, software updates do not download. This failure occurs only in Windows Server Update Services (WSUS) environments on a disconnected (air-gapped) network.
  40. For software updates that contain express installation files, SCCM synchronizes the Express.cab file and distributes it to the client. This behavior occurs even if the client does not require the Express.cab file for a given deployment. SCCM 1806 Known Issues fixed.
  41. After installing the SCCM client, the following registry key may still contain data. This leftover data can interfere with future management by either SCCM or Microsoft Intune. Maybe this will help AutoPilot Rip and Reuse where the client shows as MDM/ConfigMgr Agent managed rather than MDM managed client.
  42. Adjusting the download speed to use the unused network bandwidth (Windows LEDBAT) distribution point property does not work as expected in SCCM 1806. SCCM 1806 Known Issues fixed.
  43. Promoting a passive site server to active mode may fail. This issue can occur if the SDK provider’s installation on the passive server overwrites information in the SMS registry key.
  44. The SCCM console may stop unexpectedly when you try to open a new window, such as the Task Sequence Editor window.
  45. The MP_GetSuperPeerContentLocations peer cache stored procedure is optimized to improve SQL performance and accuracy of results.
  46. Multiple improvements are made to the Lifecycle Dashboard.
  47. After you change a task sequence that contains a hidden variable, that variable may be overwritten with incorrect information, which results in the task sequence failing to run.
  48. Third-party software update catalogs or file contents that contain a space in the URL or file name do not synchronize or publish.
  49. When changes are made to controlled folder access, the Exploit Guard policy does not affect clients as expected. SCCM 1806 Known Issues fixed.
  50. After you update to SCCM 1806, the Browse button is disabled incorrectly for Product Codes in Windows Installer properties in the SCCM console.
  51. When the administrator must approve a request for this application on the device option is enabled, the Software Center displays an approved application for a given user on another device. For example, if a user requests and is approved for an application from computer Desktop1, that same request is listed as approved when logged into computer Desktop2. SCCM 1806 Known Issues fixed.
  52. The SMS Executive service (smsexec.exe) may stop unexpectedly when it processes client health data.
  53. The uninstall process may fail for a high-availability site previously configured as the passive server. The FailOverMgr.log contains entries that resemble the following:  Failed to get installation directory for site server {old_site_server_name}
  54. The site database may grow unexpectedly after you add an Azure Active Directory tenant to the SCCM console. This issue occurs because of the addition of extraneous audit information to the site database.
  55. Suspending a phased deployment configured to begin sometime in the future may result in the client starting that deployment instead.
  56. Installing a passive, high-availability site server may fail if the target server is configured to use a named instance of the site database in an Always On Availability Group. Additionally, errors that resemble the following are recorded in the SCCM Setup log: CTool::ConvertNETBIOSToFQDN: getaddrinfo failed on {server_name}\{instance_name}, WSA error = 11001
  57. The Windows Server Update Services (WSUS) SCCM component on a site server does not communicate with a remote WSUS Server when a proxy is configured for that site server.
  58. Certificate selection parameters are not recognized during new client installation if they are passed using a configuration file.
  59. Member clients incorrectly look for a deployment lock after disabling the Server Group option for a collection. When this issue occurs, the client cannot install updates.
  60. After you update SCCM 1806, co-managed devices may not run deployments targeted to users.
  61. The Install software packages are automatically selected according to the dynamic variable list option. This issue occurs after changing an existing task sequence in the task sequence editor to add Install-Package actions.
  62. Adding a Run Command Line step to an existing task sequence that updates the operating system fails. Additionally, an error that resembles the following is displayed in the Task Sequence Editor:

ConfigMgr Error Object: Instance of SMS_ExtendedStatus
Description = “Failed to validate property TargetDrive.”;
ErrorCode = 2147500037

63. Replication failed between CAS and Primary site as Site Data “Site Server Monitor Status” was failing with the following error in rcmctrl.log:

Error: Exception message: [Cannot drop type ‘SCCM_DRS_AlwaysOn_Server_MonitoringStatus_TYPETEMP’ because it is being referenced by object ‘spUpsertAlwaysOn_Server_MonitoringStatus’. There may be other objects that reference this type.] SMS_REPLICATION_CONFIGURATION_MONITOR

Resources

https://support.microsoft.com/en-us/help/4465865/software-updates-do-not-download-in-configmgr-if-wsus-is-disconnected

1806 Slow Ring – https://support.microsoft.com/en-us/help/4459354/interoperability-update-for-system-center-configuration-manager

1806 Fast Ring – https://support.microsoft.com/en-gb/help/4346645/update-for-system-center-configuration-manager-version-1806-first-wave
